Retrofitting lashing eyes in vans and trailers

Retrofitting lashing eyes in vans and trailers

Load securing is becoming increasingly important. Due to increased police checks and greater awareness of load securing and safety, more and more people are securing their loads in vans and trailers. However, as many vans do not have a sufficient number of lashing eyes and lashing points, these need to be retrofitted. Lashing points are often missing altogether, as they are not included as standard in many vehicles. Retrofitting lashing points should be carried out by a professional, as the lashing points and lashing eyes have to withstand enormous loads depending on the load being transported.

Why should lashing eyes be retrofitted?

In principle, lashing eyes can be retrofitted to trailers and vans. Both variants have their own pitfalls, but offer an extremely high level of safety. This is because having a sufficient number of lashing points makes it easier to secure the load and, above all, ensures that it is more stable.
The shorter the distances for lashing and securing loads, the more durable and stable the load can be secured. Anyone wishing to retrofit lashing eyes should therefore ensure that they are of the highest possible quality and install them in strict accordance with legal requirements. Adventurous constructions and direct screw connections to the loading area of the transporter or trailer are unprofessional and unsafe. Retrofitting lashing eyes to trailers is usually relatively easy, as most trailers can be easily accessed from below. Anyone wishing to retrofit lashing eyes to their trailer can therefore do so quickly and easily.
However, if you want to retrofit lashing eyes to a van, you will usually need a lifting platform or at least a work pit.

Retrofitting lashing eyes in your van: what you need to bear in mind

Lashing eyes are usually retrofitted to the floor of vehicles. However, the mounting options vary greatly depending on the vehicle, model and manufacturer. Many buses and vans have 10 mm threaded holes in the floor area to which lashing eyes or even seats can be attached. These offer sufficient stability to allow lashing eyes to be retrofitted quickly and easily. However, if such holes are not available, the new lashing eyes should always be fastened with a suitable counterplate. This means that the floor of the vehicle must be drilled through. The counterplate must then be fastened so that it rests on the stable and load-bearing parts of the bodywork in order to ensure the highest possible tensile strength.

However, this is often difficult for beginners and laymen to assess. In this case, it is definitely recommended to visit a specialist workshop to retrofit lashing eyes.
